Scissor Lift

Product Details:

We are the leading supplier of Scissor Lift made available to our clients at competitive prices.

Product Details:

Good Lifts is used for various material handling applications such as material shifting from shop floor to up stairs and maintenance work, we offer a wide range of Goods Elevator. These are controlled with height limit switches and provided with mechanical stoppers that increase the efficiency of the Lift. To suit the varied requirements of the clients, we can also offer the customized range of the lift within committed time frame.
Features:

Capacity: 500 & 1000 Kgs. Lift: Up to 15 Mtr (with Decrease in Weight Capacity)Used for material shifting from shop floor to up stairsThese are self standing lifts & no civil work like duct is neededUp & down movement with fully automatic Electro Hydraulic Power Pack Adjustable overload protection valve gives safety against overloading Power pack is on ground for easy maintenance workUp & down movement are controlled by height limit switches in addition to mechanical stoppersOccupies small space on shop floorTwo lifting chains & 2 stand by ropes are provided as standard features
Technical Specifications:

Load Carrying Capacity (kg)
500
Max. Platform Height H1 (mm)
4000
Min. Platform Height H2 (mm)
125
Platform Length L (mm)
1200
Platform Width W (mm)
1200
Overall Width W1 (mm)
1700
Overall Height H3 (mm)
6000
Cage Height H4 (mm)
1500


Other InformationPay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer)

Product Details:

We are the leading supplier of Scissor Lift made available to our clients at competitive prices.

Product Details:

We are offering to our clients Heavy Duty Scissor Lifts, which are ideal for heavy duty application under the toughest working conditions. These have scissor leg rollers, entrapped within the structure of the platform and base frame to ensure maximum unit stability on all four sides.

Feature :

• Hydraulic pump with built-in overload relief.
• Full-length deck beam for maximum support.
• Solid plate scissor legs for maximum rigidity.
• Chequered Plate deck and lip with chain.
• All pivot points equipped with lubricated nipples.
• Lowering brake valve to prevent platform free fall.
• Completely sealed, weather resistant gliders and piston.
• Motor, controls, push button factory pre-wired and tested.

Product Details:

Good Lifts is used for various material handling applications such as material shifting from shop floor to up stairs and maintenance work, we offer a wide range of Goods Elevator. These are controlled with height limit switches and provided with mechanical stoppers that increase the efficiency of the Lift. To suit the varied requirements of the clients, we can also offer the customized range of the lift within committed time frame.
Features:

Capacity: 500 & 1000 Kgs. Lift: Up to 15 Mtr (with Decrease in Weight Capacity)Used for material shifting from shop floor to up stairsThese are self standing lifts & no civil work like duct is neededUp & down movement with fully automatic Electro Hydraulic Power Pack Adjustable overload protection valve gives safety against overloading Power pack is on ground for easy maintenance workUp & down movement are controlled by height limit switches in addition to mechanical stoppersOccupies small space on shop floorTwo lifting chains & 2 stand by ropes are provided as standard features
Technical Specifications:

Load Carrying Capacity (kg)
500
Max. Platform Height H1 (mm)
4000
Min. Platform Height H2 (mm)
125
Platform Length L (mm)
1200
Platform Width W (mm)
1200
Overall Width W1 (mm)
1700
Overall Height H3 (mm)
6000
Cage Height H4 (mm)
1500


Other InformationPay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer)

Product Details:

Leveraging on our expansive distribution network, we procure and deal in a high performing range of Hydraulic Car Scissor Lift. These are manufactured using solid and quality approved materials, which are directly sourced from the authenticated vendors of the industry. We fabricate our range in accordance with industrial standards and are widely used for building.

Features:



• Specially designed as per customers requirement.
• Special care has been taken while designing and manufacturing for improved performance & servicing
• Features ultra modern look which is its added value and provides elegance to working area



Other Details:

The Limit Switch System Helps The Lift To Stop At Accurate Position.

All The Lifts Are Passed.

Two Times Loading Test Before Leaving Factory.

The Hydraulic Cylinders And Hose Are Armed With Explosion-Proof Lock Valve To Avoid A Sudden Drop Once Hydraulic Pipe Breaks, The Work Platform Will Be Down Slowly To Ensure Safety Of Goods.

Emergency Button Is Available On Each Control Box, When Emergency Occurs, The Immediate STOP Can Be Realized.5. Overload Protection Facility Is Equipped On, The Lift Will Not Work When Goods Is Overloaded.

Maintenance Window Is Made In The Middle Of Work Platform; It Is For Your Convenience To Maintain The Lift In Future.

There Are 2 Sets Control System Are Installed On The Lift, 1 Control Box Below, And 1 Control Panel On Handrail That Can Be Operated On Work Platform.

Custom-Made Products Are Done According To Detailed Request, Please Tell Us Load Capacity, Lift Height, And Platform Size You Need, Our Engineer Will Design A Suitable Lift For You Soon.

Product Details:

Leveraging on our expansive distribution network, we procure and deal in a high performing range of Hydraulic Car Scissor Lift. These are manufactured using solid and quality approved materials, which are directly sourced from the authenticated vendors of the industry. We fabricate our range in accordance with industrial standards and are widely used for building.

Features:



• Specially designed as per customers requirement.
• Special care has been taken while designing and manufacturing for improved performance & servicing
• Features ultra modern look which is its added value and provides elegance to working area



Other Details:

The Limit Switch System Helps The Lift To Stop At Accurate Position.

All The Lifts Are Passed.

Two Times Loading Test Before Leaving Factory.

The Hydraulic Cylinders And Hose Are Armed With Explosion-Proof Lock Valve To Avoid A Sudden Drop Once Hydraulic Pipe Breaks, The Work Platform Will Be Down Slowly To Ensure Safety Of Goods.

Emergency Button Is Available On Each Control Box, When Emergency Occurs, The Immediate STOP Can Be Realized.5. Overload Protection Facility Is Equipped On, The Lift Will Not Work When Goods Is Overloaded.

Maintenance Window Is Made In The Middle Of Work Platform; It Is For Your Convenience To Maintain The Lift In Future.

There Are 2 Sets Control System Are Installed On The Lift, 1 Control Box Below, And 1 Control Panel On Handrail That Can Be Operated On Work Platform.

Custom-Made Products Are Done According To Detailed Request, Please Tell Us Load Capacity, Lift Height, And Platform Size You Need, Our Engineer Will Design A Suitable Lift For You Soon.

Product Details:

Leveraging on our expansive distribution network, we procure and deal in a high performing range of Hydraulic Car Scissor Lift. These are manufactured using solid and quality approved materials, which are directly sourced from the authenticated vendors of the industry. We fabricate our range in accordance with industrial standards and are widely used for building.

Features:



• Specially designed as per customers requirement.
• Special care has been taken while designing and manufacturing for improved performance & servicing
• Features ultra modern look which is its added value and provides elegance to working area



Other Details:

The Limit Switch System Helps The Lift To Stop At Accurate Position.

All The Lifts Are Passed.

Two Times Loading Test Before Leaving Factory.

The Hydraulic Cylinders And Hose Are Armed With Explosion-Proof Lock Valve To Avoid A Sudden Drop Once Hydraulic Pipe Breaks, The Work Platform Will Be Down Slowly To Ensure Safety Of Goods.

Emergency Button Is Available On Each Control Box, When Emergency Occurs, The Immediate STOP Can Be Realized.5. Overload Protection Facility Is Equipped On, The Lift Will Not Work When Goods Is Overloaded.

Maintenance Window Is Made In The Middle Of Work Platform; It Is For Your Convenience To Maintain The Lift In Future.

There Are 2 Sets Control System Are Installed On The Lift, 1 Control Box Below, And 1 Control Panel On Handrail That Can Be Operated On Work Platform.

Custom-Made Products Are Done According To Detailed Request, Please Tell Us Load Capacity, Lift Height, And Platform Size You Need, Our Engineer Will Design A Suitable Lift For You Soon.

Product Details:

Hydraulic Platform Lift.

Product details:

Product description:

We are offering Hydraulic Scissors Car Lift to our clients.

Application:

• Shifting cars from one floor to another.
• Car Parking (Malls, Complex, etc.)
• Car storage
• Multi-Level Parking System.
• Loading and unloading of automobiles.
• Transportation.

Note: Approx. price: 4 - 10 lakhs

Product Details:

Our organization is counted amongst the most distinguished supplier of qualitative Scissor Lift. All the offered lifts find their applications in commercial buildings, car dealer showrooms, car parks and offices. Precisely designed, all the lifts are made using quality-tested components, equipment and tools.

Features:

• Low noise
• Five point automatic safety
• Simple operation

Other Details:

• Remote control
• Speed control
• Weight sensor
• Low noise
• Five point automatic safety
• Most simple operation
• Durable long life design
• Custom platform and lift stroke
• Personnel lift modifications
• Platform can incorporate conveyor, personnel station, boom gates, light curtains, hand rails, load flaps, special surface treatments, checker plate.
• Unique to FIPL is our Energy Regeneration System which reduces running costs by regenerating electrical power
• It can besupplied on large lifts with higher travel

Application:

• Commercial buildings
• Car dealer showrooms
• Private residence
• Car parks
• Offices
• Mezzanine Lifts Basic Design
• Theatre and stage installations
• Freight Hoists
• Container handling, Vehicle and aircraft manufacture and maintenance, Car and truck movement, Container movement on ships
• Work Platforms
• Personnel Lifts & Goods Lifts
• Dock Loading Platforms

Specifications:

Product Details:

Good Lifts is used for various material handling applications such as material shifting from shop floor to up stairs and maintenance work, we offer a wide range of Goods Elevator. These are controlled with height limit switches and provided with mechanical stoppers that increase the efficiency of the Lift. To suit the varied requirements of the clients, we can also offer the customized range of the lift within committed time frame.
Features:

Capacity: 500 & 1000 Kgs. Lift: Up to 15 Mtr (with Decrease in Weight Capacity)Used for material shifting from shop floor to up stairsThese are self standing lifts & no civil work like duct is neededUp & down movement with fully automatic Electro Hydraulic Power Pack Adjustable overload protection valve gives safety against overloading Power pack is on ground for easy maintenance workUp & down movement are controlled by height limit switches in addition to mechanical stoppersOccupies small space on shop floorTwo lifting chains & 2 stand by ropes are provided as standard features
Technical Specifications:

Load Carrying Capacity (kg)
500
Max. Platform Height H1 (mm)
4000
Min. Platform Height H2 (mm)
125
Platform Length L (mm)
1200
Platform Width W (mm)
1200
Overall Width W1 (mm)
1700
Overall Height H3 (mm)
6000
Cage Height H4 (mm)
1500


Other InformationPay Mode Terms: L/C (Letter of Credit), T/T (Bank Transfer)

Product Details:

Product Details:

Leveraging on our expansive distribution network, we procure and deal in a high performing range of Hydraulic Car Scissor Lift. These are manufactured using solid and quality approved materials, which are directly sourced from the authenticated vendors of the industry. We fabricate our range in accordance with industrial standards and are widely used for building.

Features:



• Specially designed as per customers requirement.
• Special care has been taken while designing and manufacturing for improved performance & servicing
• Features ultra modern look which is its added value and provides elegance to working area



Other Details:

The Limit Switch System Helps The Lift To Stop At Accurate Position.

All The Lifts Are Passed.

Two Times Loading Test Before Leaving Factory.

The Hydraulic Cylinders And Hose Are Armed With Explosion-Proof Lock Valve To Avoid A Sudden Drop Once Hydraulic Pipe Breaks, The Work Platform Will Be Down Slowly To Ensure Safety Of Goods.

Emergency Button Is Available On Each Control Box, When Emergency Occurs, The Immediate STOP Can Be Realized.5. Overload Protection Facility Is Equipped On, The Lift Will Not Work When Goods Is Overloaded.

Maintenance Window Is Made In The Middle Of Work Platform; It Is For Your Convenience To Maintain The Lift In Future.

There Are 2 Sets Control System Are Installed On The Lift, 1 Control Box Below, And 1 Control Panel On Handrail That Can Be Operated On Work Platform.

Custom-Made Products Are Done According To Detailed Request, Please Tell Us Load Capacity, Lift Height, And Platform Size You Need, Our Engineer Will Design A Suitable Lift For You Soon.

Product Details:

We are engaged in manufacturing and supplying a wide assortment of Die Loaders. These loaders are manufactured in adherence with the set industry standards and norms using high-grade raw material and advanced technology.



Owing to their features like easy operation, simple fitting and manually operated unit, these loaders are widely demanded by the clients. Moreover, our offered products are also known for their easy installation and maximum comfort.

Product Details:

Main Features:



1. Pointing control of lifting up and down.

2. Manganese steel lifting arm in high strength with rectangle shape

3. Anti-skid floor in platform

4 The control panels are available on the platforms and ground.

5. Fine grinding cylinder in good sealing performance

6. Neatly folding guardrails make it easy to maneuver through doorways, into elevators and throughout other height-restricted areas.





Safety Precaution:



1. The operation voltage on the platform is 24V

2. Emergency stop button on the platform and ground

3. Auxiliary platform lowering

4. Telescopic legs on the chassis

5. Hose burst valve safety

6. Rain-proof design electric cabinet

7. Fence on the platform





Major Parameters

• Model: SJZ0.3-14
• Loading Capacity 300kg
• Maximum Height 14000mm
• Minimum Height 2000mm
• Platform Size 2450*1350mm
• Lifting Power 2.2kw*2
• Motorized Power: 1.2Kw
• Power Voltage DC24V
• Lifting Time 118s
• Cylinder ??100(3Pcs)
• Gear Pump 6ml/r
• Total Weight 2180kg
• Measurement 2750*1740*2000mm



Optional Configurations:

• Electric system: Schneider contactor, SANLICO button, CHNT electrical
• Hydraulic System: Hycman brand power pack ,NOK sealing
• Scissor Arm Support: Hi-strength Manganese steel rectangle tube Q345 B
• Platform Surface : Antiskid checkered plate
• Tire: Ø500-8 Inflated tires
• High-pressure Oil Pip: Double wire hydraulic intensifier rubber hose :
• Battery: (DC12V,150AH)*4 with charger

Product Details:

we are the leading Manufacture of Aerial Lifts.

we are looking customer from Pan India.
